Additional information
| Weight | 0.045 kg |
|---|---|
| Dimensions | 15 × 20 × 4 cm |
| Brand Name | Meshzeno |
| Battery Included | No |
| Typical Application Fields | Internet of Things (IoT) |
| High-concerned chemical | None |
| Model Number | LoRa 32 V4 |
| Origin | Mainland China |
| Master Chip | ESP32-S3R2 |
| LoRa Chip | SX-1262 |
| Frequency | 433~510 MHz, 863~928 MHz |
| Max. TX Power | 21±1dBm, 27±1 dBm |
| Max. Receiving Sensitivity | -137 dBm |
| Wi-Fi | 802.11 b/g/n, up to 150Mbps |
| Bluetooth | Bluetooth LE, Bluetooth 5, Bluetooth mesh |
| OLED | SSD1315(0.96Inch, 128*64 resolution) |
| Power Supply | 5V@USB, 3.3-4.2V@Battery |
| Operating Temperature | -40~85℃(OLED operating temperature: -40~ 70°C) |
| Dimensions | 51.7 * 25.4* 10.7mm |
| Choice | yes |
| semi_Choice | yes |
